Selection of products for INGOLSTADT Roving Frames
FOR PRODUCTS NOT LISTED BELOW, PLEASE DO NOT HESITATE TO CONTACT US.
We also make special and custom made flyers for all types of roving frames, in all sizes.


INGOLSTADT FB 11 | FW 11
TOP-DRIVEN FLYERS
for specification please use Questionnaire UGK/UGKL

Flyer model UGK
  • cast-in polished stainless steel tube from top to exit
  • high precision dynamic balancing up to 1800 rpm
  • heat-treated special steel presser (various designs)
  • special anti-lint surface finish
  • HOLZ twist cap
Flyer model UGKL
  • for back row of roving frames, to equalize the roving angle between flyer entrance and drafting system
  • other specifications as above

INGOLSTADT F 4300 | FB 6 | FB 7 | GB 7 | 260
FLYERS
for specification please use Questionnaire UGR/UGRL

Flyer model UGR
  • Specially hardened steel cone part to fit the original spindle
  • cast-in polished stainless steel tube from top to exit
  • high precision dynamic balancing throughout the total operative speed range from 600 to 1400 rpm.
  • heat-treated special steel presser (various designs)
  • special anti-lint surface finish
  • HOLZ twist cap
Flyer model UGRL
  • for back row of roving frames, to improve the roving angle between flyer entrance and drafting system
  • other specifications as above
Flyer model UGRH
  • Special design for worsted and long staple, with oxide ceramic insert.
Accessories for INGOLSTADT Flyers

Twist Caps
  • various types of HOLZ Twist Caps available
Pressers
  • Made of heat treated carbon steel with anti-static surface finish. Various shapes available.
Fixing Parts
  • Bushes, pins and screws in top standard quality
